Malmbergs – Charging station Evon Dual, 2x11kW, 32A, with 7 m cable, Type 2

Malmbergs EVON DUAL is a charging station designed to be user-friendly both in public places and at home. Features include load management, consumption monitoring and much more. Starting charging with an RFID card, the EVCHARGO app or as soon as the charging cable is connected to the vehicle makes it both flexible and easy to use. EVON DUAL is available in different versions: either with a fixed cable or a socket, and with or without a MID-approved energy meter for accurate measurement of energy consumption. Its safety features, including a type A residual current device with 6mA DC detection, provide a safe charging environment. Up to 22 kW charging power and the option to connect via WiFi, 4G, Ethernet or Bluetooth offer a convenient and adaptable charging solution. The indicator light on the front clearly shows the charging status in different colours (red, yellow, green), making use easy and intuitive. For wall or post mounting. Easy to install thanks to the base plate that is mounted first. Six cable entries and plenty of installation space for easy and flexible installation. • Adjustable charging current • Control charging via WiFi, Ethernet, Bluetooth or 4G • Includes a SIM card • Charging start: RFID / App / Direct charging • Efficient charging speed • Charging scheduling via the app • Safe in offline mode. Stable and reliable connection via Bluetooth • Load management (optional) • 2 RJ45 network ports for easy daisy-chaining • RFID reader • DC monitoring • Built-in protection with a type A residual current device • Indicator light (RGB) • Easy daisy-chaining with 25 mm² double terminals • 5-year warranty NOTE! Not compatible with wired load management, ADL400 (9909000).
