Cable-free, screw-free, worry-free – that is how installing ZYC’s new SIMPO HV storage system works. The proven stacking concept allows up to 28.8 kWh of usable capacity per unit. And that’s not all – up to 8 towers with a total of 230.4 kWh can be connected in parallel. The range of applications therefore extends from residential buildings to small commercial systems.
Product benefits:
– Powerful, compact stacked design
– Cable-free and screw-free design
– Up to 8 towers can be cascaded (230.8 kWh).
– Battery safety certified to VDE 2510-50.
Product features – storage:
– Battery capacity (usable): 19.2 kWh
– Extension window: unlimited
– Cell chemistry: LFP
– Interfaces: RS485, Modbus RS485.
– System configuration: 2 – 9 storage modules
– Cascadable: up to 8 towers in parallel.
– Nominal voltage: 384 V
– Protection class: IP65
– Dimensions (height x width x depth): 1430 x 450 x 296 mm.
– Weight: BMS + base: 20.0 kg, 6 x storage unit 36.0 kg each.
– Warranty: 10 years
Scope of delivery:
– 1 x ZYC SIMPO HV battery management system (item 0157730)
– 6 x ZYC SIMPO HV storage module (item 0157729).
